H07V-K 4 mm² Black
Article number
344010109BK
Description
PVC insulated wire
- Number of conductor: 1.
- Conductor diameters: 4mm².
- Outer cable diameter: 3,9mm.
- Conductor: flexible bare copper (class 5).
- Insulation: PVC TI1.
- Maximum conductor temperature: 70°C.
- Rated temperature fixed installation: -5°C to 70°C.
- Rated temperature flexible installation: 5° to 70°C.
- Rated bending radius: 4 x ø.
- Fire behaviour according to IEC 60332-1-2 (flame retardant).
- Application: for laying in pipes on top of or under plaster and in closed installation ducts and for internal wiring of machinery, swithgear and distributor systems.
- NOT suitable for direct laying under plaster.
- Number of conductor: 1.
- Conductor diameters: 4mm².
- Outer cable diameter: 3,9mm.
- Conductor: flexible bare copper (class 5).
- Insulation: PVC TI1.
- Maximum conductor temperature: 70°C.
- Rated temperature fixed installation: -5°C to 70°C.
- Rated temperature flexible installation: 5° to 70°C.
- Rated bending radius: 4 x ø.
- Fire behaviour according to IEC 60332-1-2 (flame retardant).
- Application: for laying in pipes on top of or under plaster and in closed installation ducts and for internal wiring of machinery, swithgear and distributor systems.
- NOT suitable for direct laying under plaster.
